| Products => Terminal => Receptacles RE637 straight Series |
| กก |
|
|
|
|
|
|
| Part No | Applicable wire |
Fit Tab Thickness (mm) |
Material | Finish | Qty / Reel | Approval | |
| AWG | mm2 | ||||||
| RE6370801-40 | 18-16 | 0.8-1.3 | 0.8 | Brass | Natural | 3000 | ---- |
| RE6370802-40 | 18-16 | 0.8-1.3 | 0.8 | Brass | Tinned | 3000 | ---- |
| RE6370804-40 | 18-16 | 0.8-1.3 | 0.8 | Brass | Nickel | 3000 | ---- |
Note :
1. Receptacles denoted by (2) is used only for two wires, If using wires in other combinations than the ones shown above, please contact Utilux South China Ltd.
2. Combine a plated straight receptacle with a plated tab and a non-plated receptacle with a non-plated tab.
