| Products => Terminal => RL58025 lock ring terminal Series |
| กก |
|
|
|
|
|
| Part No | Applicable wire | Diameter (mm) | Material | Finish | Approval | ||
| AWG | mm2 | OD | ID | ||||
| RL5802501-30 | 24-20 | 0.2-0.5 | 5.8 | 2.5 | Brass | Natural | ---- |
| RL5802501-40 | 24-20 | 0.2-0.5 | 5.8 | 2.5 | Brass | Natural | ---- |
| RL5802502-30 | 24-20 | 0.2-0.5 | 5.8 | 2.5 | Brass | Tinned | ---- |
| RL5802501-40 | 24-20 | 0.2-0.5 | 5.8 | 2.5 | Brass | Tinned | ---- |
Note :
1. Receptacles denoted by (2) is used only for two wires, If using wires in other combinations than the ones shown above, please contact Utilux South China Ltd.
2. Combine a plated straight receptacle with a plated tab and a non-plated receptacle with a non-plated tab.
กก
