| Products => Terminal => SR600 Brass ribbon Series |
 |
 |
 |
| Part No |
Ribbon Width (mm) |
Thickness (mm) |
Material | Finish | Qty / Reel | Approval |
| SR6003001-30 | 6.0 | 0.3 | Brass | Natural | 120M | ---- |
| SR6003002-30 | 6.0 | 0.3 | Brass | Tinned | 120M | ---- |
| SR6003003-30 | 6.0 | 0.3 | Steel | Nickel | 120M | ---- |
| SR6003004-30 | 6.0 | 0.3 | Brass | Nickel | 120M | ---- |
| SR6004001-40 | 6.0 | 0.4 | Brass | Natural | 120M | ---- |
| SR6004002-40 | 6.0 | 0.4 | Brass | Tinned | 120M | ---- |
| SR6004003-40 | 6.0 | 0.4 | Steel | Nickel | 120M | ---- |
| SR6004004-40 | 6.0 | 0.4 | Brass | Nickel | 120M | ---- |
Note :
1. Receptacles denoted by (2) is used only for two wires, If using wires in other combinations than the ones shown above, please contact Utilux South China Ltd.
2. Combine a plated straight receptacle with a plated tab and a non-plated receptacle with a non-plated tab.
